Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac

Name: Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac
Brand: UNIMAX TRADERS
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac Specification

Feature
High interrupting rating, low It values, fast response to overcurrents

Operating Temperature
-40C to +80C

Shape
Cylindrical

Insulation Material
High-grade melamine/ceramic

Humidity %
up to 95% RH (non-condensing)

Surface Finish
Smooth, non-porous finish, corrosion resistant

Efficiency
99% (minimal energy loss under normal conditions)

Power Factor
Not Applicable (passive component)

Connector Type
Blade or bolt connection terminals

Overheating Protection
Fusible link provides overcurrent and fault protection

Mounting Type
Panel/Stud mounting

IP Rating
IP20 when properly installed

Product Type
High Speed North American Fuse (Amptrap)

Application
Semiconductor protection, inverters, drives, UPS, renewable energy systems

Protection Level
High speed, current limiting, short circuit protection

Frequency (MHz)
DC/AC application, up to 60Hz AC

Rated Voltage
700VDC, 1000VDC, 1200VAC, 1500VAC (depending on model)

Energy Consumption
Low energy consumption fuse

Output Type
Non-resettable

Color
White/Beige body with metallic end caps

Dimension (L*W*H)
Varies by part (e.g. 127 mm 34 mm 34 mm typical for 1500V)

Weight
Varies by model (contact manufacturer for specific data)

Size
Standard North American high-speed fuse sizes

Phase
Single phase

Input Voltage
700VDC/1000VDC/1200VAC/1500VAC

Material
Melamine body, copper/silver plated contacts

No Of Poles
Single-pole

Connection Type
Bolt-on end connections

Environmental Safety
RoHS compliant, lead-free construction

Typical Applications
DC fast chargers, traction systems, battery energy storage

Body Construction
Ceramic or melamine, sand-filled

Interrupting Rating
Up to 200 kA (AC), 100 kA (DC), depending on fuse rating

Storage Temperature
-40C to +120C

Compliance Standards
UL Recognized, CSA Certified, CE Marked

End Cap Material
Silver or tin-plated copper

Service Life
Dependent on load cyclingconsult manufacturer

Response Time
Ultra-fast acting (milliseconds to microseconds)

Marking
Laser-marked with ratings and approvals

Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac Trade Information

Minimum Order Quantity
100 Pieces

FOB Port
kolkata

Payment Terms
Cash in Advance (CID)

Main Export Market(s)
Asia

Main Domestic Market
All India

About Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac

Ferraz Shawmut (now Mersen) refers to a brand of industrial and electronic fuses, including specialized multi-meter fuses, Class C and Class J fuses, and compact, finger-safe fuse holders designed for power electronics, metering, and control applications. These fuses are known for their reliable technical performance, with options like high breaking capacity for short-circuit protection and finger-safe designs that meet IEC safety standards.

Exceptional Protection for High-Speed Applications

Engineered for demanding applications such as DC fast chargers, traction systems, and energy storage, these high-speed fuses deliver outstanding protection by acting within milliseconds to microseconds. Their robust design ensures reliable protection from dangerous overcurrents and short circuits, safeguarding sensitive components and maintaining system integrity.

Certified Safety and Quality Standards

Complying with international certifications like UL, CSA, and CE and meeting RoHS requirements, these fuses are safe for use worldwide. Their lead-free, low-energy design aligns with modern environmental safety standards, ensuring both operational safety and eco-friendly compliance for North American and global installations.

FAQ's of Ferraz Shawmut Mersen High Speed North American Fuse Amptrap 700vdc 1000vdc 1200vac 1500vac:

Q: How do I select the appropriate Ferraz Shawmut Mersen High Speed Fuse for my application?

A: To choose the right fuse, consider your system's voltage (700VDC, 1000VDC, 1200VAC, or 1500VAC), required interrupting rating, expected fault currents, mounting requirements, and precise application (such as inverters, drives, or UPS). For assistance with selection or to confirm dimensions and ratings, contact your supplier or the manufacturer.

Q: What benefits does this fuse offer for semiconductor protection?

A: With its ultra-fast acting response and high current-limiting capability, the fuse quickly interrupts overcurrents and short circuits, minimizing potential damage to sensitive semiconductor components and preventing costly downtime or repairs in critical applications.

Q: When is this fuse typically used in energy storage or renewable systems?

A: These fuses are ideal for use in DC fast chargers, battery energy storage systems, and renewable energy installations, protecting equipment during surges or faults by providing rapid isolation to maintain operational safety and system longevity.

Q: Where should the fuse be installed within an electrical system?

A: Install the fuse in a location that enables it to provide primary overcurrent protection, typically close to sensitive loads or power sources, such as between batteries and inverters, or upstream from semiconductor modules. Proper installation ensures efficient removal of fault currents, safeguarding the entire system.

Q: What is the process for replacing a blown fuse?

A: Before replacing, disconnect all power sources and confirm that the fuse is the correct model for your system requirements. Using the bolt-on or blade end terminals, mount the new fuse securely, ensuring firm, corrosion-free electrical contact. Always adhere to panel or stud mounting guidelines, as specified by the manufacturer.

Q: How does the ultra-fast response improve safety and reliability?

A: By reacting in milliseconds to microseconds, the fuse limits the energy let-through during faults. This high-speed action protects valuable equipment from extensive damage, reduces downtime, and supports stable, long-term operation, particularly in fast-acting industrial and renewable energy systems.

Q: What environmental and operational conditions are these fuses rated for?

A: These fuses operate within a temperature range of -40C to +80C, can be stored up to +120C, and withstand up to 95% relative humidity (non-condensing). Their construction materials and IP20 rating (when installed properly) ensure reliable performance even in challenging industrial environments.
